Lump Breakers

Lump Breakers

Lump breakers are designed to reduce large clumps of agglomerated material into smaller, more uniform particles to support consistent material flow. Progressive Products Inc. lump breakers are commonly used with materials such as chemicals, ash, sugar, food products, and plastics. Units are available in 12” x 12” and 24” x 24” sizes and can be fabricated in 304 stainless steel, 316 stainless steel, or carbon steel to meet application requirements.

While lump breakers effectively break down material buildup, they are not intended to function as precision size-reduction or grinding equipment. To ensure proper performance, material testing is recommended to confirm correct unit sizing, along with downstream level sensors to prevent overfilling of the feeding device. Customers may submit material for in-house testing to verify suitability before installation.

  • Increase efficiency with improved downstream processing
  • Once-through process
  • Minimal waste
  • Operator-friendly
  • Efficiently throughput up to 20 tons per hour

Size:

  • 12” x 12” (30.5 cm x 30.5 cm)
  • 24” x 24” (60.9 cm x 60.9 cm)

Options:

  • 304 stainless steel, 316 stainless steel, and carbon steel construction available
  • Explosion-proof available
  • Washdown available

For dry bulk materials that tend to clump when exposed to moisture, including:

  • Ash
  • Chemicals
  • Coal
  • Detergents
  • Filter cake
  • Foods (salt, sugar, etc.)
  • Gypsum
  • Herbicides
  • Kiln dust
  • Pigment
  • Plastics

How lump breakers work

As dry bulk material passes through the lump breaker, rotating teeth break clumped material apart into smaller particles. This lets you maintain consistent flow in pneumatic systems with lower energy requirements, and boost the value of the final product.

Our lump breakers also come with long-life bearings and maintenance-free seals to prevent clogging, as well as factory-installed air purge to keep components clean.

The Role of Lump Breakers in Reducing Material Waste and Costs

Lump breaker or hammermill?

A lump breaker breaks apart material that has clumped during production, storage or transport to improve flow into the next process. A hammermill is used for grinding and further size reduction. If your material is already the size you need but has formed clumps, a lump breaker may be the right choice. It is not precision grinding equipment; material testing helps confirm suitability. Read our lump breaker vs hammermill comparison.

Where lump breakers are used

Lump breakers help handle dry bulk materials such as chemicals, ash, sugar, food ingredients and plastics. The right unit depends on the material and the process. Send a material sample for in-house testing to confirm suitability and sizing.

Lump breaker sizing and selection questions

What throughput can a lump breaker handle?

Progressive Products lists throughput up to 20 tons per hour. Material testing is recommended to confirm the right unit for your application.

What sizes are available?

Available unit sizes are 12 × 12 inches and 24 × 24 inches.

What construction materials are available?

Units can be fabricated in 304 stainless steel, 316 stainless steel or carbon steel.

Is a lump breaker a precision grinder?

No. It breaks up clumped material in a once-through process with minimal waste. It is not intended for precision size reduction or grinding.

Lump breaker infographic comparing the PPI lump breaker with a generic unit: up to 20 tons per hour, 12 or 24 inch square sizes in 304SS, 316SS or carbon steel.
